Temperature specification

Temperature control range            -70℃~180℃(A:0℃~180℃;B:-20℃~180℃;C:-40℃~180℃;D:-70℃~180℃)

Temperature variation

±0.5℃

The temperature drop rate is 180.0°C~-70.0°C, about 1.0~3.0°C/min within 100 minutes

The rate at which the temperature rises

-70.0°C~180.0°C, about 60 minutes, 3.0~5.0°C/min

Degree of temperature distribution

±1.5℃(-40.0℃~100.0℃)

±2.0℃(100.1℃~180.0℃or-40.0℃~-70.0℃)

 Temperature specification

Humidity control range

20.0%RH~98.0%RH (20%RH for 60°C or more)

Humidity variability ±1.0% RH

Humidity distribution

±2.0%RH

 Material/

Component

Interior Material: 1.2mm thick stainless steel plate (SUS304)

Exterior Material

It is coated with 1.2mm cold-rolled steel plate/powder coating

Thermal insulation material: 100mm thick polyurethane board + 10mm thick glass wool

Fans

Impeller Fan

Compressor fully enclosed/semi-hermetic

Semi-enclosed

Condenser

Air-cooled or water-cooled

Refrigerant                                          R404A、R23、R508

Evaporator

Finned tubular heat exchanger

Heater                       Nichrome heating wire

Humidifier

Steam humidifiers

 Dimensions

Inner box size
(LxWxH)

350mmx500mmx340mm

580mmx750mmx450mm

580mmx750mmx765mm

800mmx950mmx800mm

1000mmx1000mmx1000mm

1000mmx1500mmx1200mm

1500mmx1800mmx1850mm

2000mmx2000mmx2000mm

Exterior dimensions
(LxWxH)

630mmx1180mmx971mm

895mmx1800mmx1570mm

895mmx1800mmx1885mm

1115mmx2000mmx1930mm

1200mmx2050mmx1780mm

1200mmx2000mmx2650mm

1700mmx2150mmx3300mm

2300mmx2450mmx3600mm

Capacity (L)

60

180

 340

600

1000

1800

5000

8000

Power Specifications

220V AC50/60Hz

 380V AC50/60Hz

Controller

Independent research and development of controllers
